TEAC AP-507 – Power in a Compact Case

16.02.2025 06:09 | ~1 minute read

TEAC has introduced the compact TEAC AP-507 two-channel power amplifier, which implements the latest Hypex NCOREx Class D technology. Compared to its predecessor AP-505, the TEAC AP-507 is equipped with an updated amplifier module with higher output power and low distortion. In addition, the TEAC AP-507 amplifier supports bridge mode for use as a powerful monoblock.

TEAC AP-507
TEAC AP-507. Image source - (c) TEAC

The TEAC AP-507 uses a new generation NCOREx power amplifier module from TEAC, developed jointly with Hypex and operating in Class D. The TEAC AP-507 in stereo mode develops up to 70 watts per channel at an 8 ohm load and 125 watts for a 4 ohm load. When bridged, the output power increases to an impressive 230 watts at an 8 ohm load. Such characteristics are provided by a power supply based on a large toroidal transformer and a filter with capacitors with a total capacity of 18,800 μF for each channel.

TEAC AP-507
TEAC AP-507. Image source - (c) TEAC

The case of the new product is made of aluminum and steel with a semi-floating top panel made of 2.8 mm thick aluminum and uses a system on three anti-vibration supports Stress-Less Isolation Foot. The front panel of the TEAC AP-507 amplifier is decorated with VU meters with a four-stage dimmer for the backlight brightness. The TEAC AP-507 stereo power amplifier is expected to be available in the spring 2025 at a recommended retail price of $ 2,199 / € 1,899.

Specifications

This product is in the Hi-Fi and High End Electronics and Acoustics database

Power amplifiers stereo — TEAC AP-507

  • Model name

    AP-507

  • Input sensitivity (mV)

    1.3 - 0.66

  • Input impedance (balanced) (Ω)

    10000

  • Input impedance (single-ended) (Ω)

    10000

  • Output impedance (balanced) (Ω)

    N/A

  • Output impedance (single-ended) (Ω)

    N/A

  • Max current (A)

    N/A

  • Output power (8Ω) (W)

    2 x 70

  • Output power (4Ω) (W)

    2 x 125

  • Gain (dBu)

    N/A

  • Frequency response low +/- 3dB (Hz)

    10

  • Frequency response high +/- 3dB (Hz)

    50000

  • Signal to Noise Ratio (dB)

    113

  • Total Harmonic Distortion + Noise (0% global feedback) (%)

    N/A

  • Total Harmonic Distortion + Noise (100% global feedback) (%)

    0.0015

  • Max power consumption (W)

    N/A

  • Damping factor

    N/A

  • Dimensions (mm)

    290 × 84.5 × 271

  • Weight (kg)

    4.4

  • Official link
