Preamplifiers — Luxman CL-1000

Description, images, technical data and specifications

Luxman CL-1000
Image source — © Luxman

Externally, the Luxman CL-1000 is similar to the classic Luxman C-1000 model - but, according to the company, the device has radically changed its circuitry. The core of the Luxman CL-1000 is the LEKUTA transformer unit (Luxman Electrically Controlled Ultimate Transformer Attenuator), which uses 34 positions.

What is it?

Ask AI to scan specialized sites and forums, evaluate the impressions of using the product, its advantages and disadvantages and get a summary.

Specifications

  • Model name

    CL-1000

  • Analog inputs (balanced)

    1

  • Analog inputs (single-ended)

    3 + 1 (Phono)

  • Analog outputs (balanced)

    2

  • Analog outputs (single-ended)

    2

  • Gain (dBu)

    N/A

  • Input sensitivity (mV)

    180

  • Output voltage (V)

    N/A

  • Input impedance (balanced) (Ω)

    70 000

  • Input impedance (single-ended) (Ω)

    90 000

  • Output impedance (balanced) (Ω)

    1000

  • Output impedance (single-ended) (Ω)

    1000

  • Maximum output level (balanced) (dBu)

    N/A

  • Maximum output level (single-ended) (dBu)

    N/A

  • Volume control range (dBu)

    N/A

  • Frequency response low +/- 3dB (Hz)

    20

  • Frequency response high +/- 3dB (Hz)

    20 000

  • Signal to Noise Ratio (SNR, unweighted) (dB)

    120

  • Total Harmonic Distortion + Noise (THD+N) (%)

    0.016

  • Dimensions (mm)

    460 x 166 x 454

  • Weight (kg)

    24.4

  • Official link

    https://www.luxman.com/product/detail.php?id=35
