Preamplifiers — Luxman C-700u

Description, images, technical data and specifications

Luxman C-700u
Image source — © Luxman

The Luxman C-700u preamp inherits the versatility and high sound quality of the C-600F, but has a higher gain: 12 dB versus 10.5 dB for the C-600F. Externally, the C-700u is similar to its fully balanced older brother, the C-900u, but does not have a symmetrical circuit topology, despite the presence of XLR connectors.

What is it?

Ask AI to scan specialized sites and forums, evaluate the impressions of using the product, its advantages and disadvantages and get a summary.

Specifications

  • Model name

    C-700u

  • Analog inputs (balanced)

    2

  • Analog inputs (single-ended)

    5

  • Analog outputs (balanced)

    2

  • Analog outputs (single-ended)

    2

  • Gain (dBu)

    N/A

  • Input sensitivity (mV)

    250

  • Output voltage (V)

    1

  • Input impedance (balanced) (Ω)

    67 000

  • Input impedance (single-ended) (Ω)

    46 000

  • Output impedance (balanced) (Ω)

    600

  • Output impedance (single-ended) (Ω)

    90

  • Maximum output level (balanced) (dBu)

    N/A

  • Maximum output level (single-ended) (dBu)

    N/A

  • Volume control range (dBu)

    N/A

  • Frequency response low +/- 3dB (Hz)

    5

  • Frequency response high +/- 3dB (Hz)

    120 000

  • Signal to Noise Ratio (SNR, unweighted) (dB)

    122 (XLR) + 125 (RCA)

  • Total Harmonic Distortion + Noise (THD+N) (%)

    0.010 (XLR) + 0.007 (RCA)

  • Dimensions (mm)

    440 x 130 x 430

  • Weight (kg)

    14.6

  • Official link

    https://www.luxman.com/product/detail.php?id=20
