Power amplifiers stereo — NAD M23
Description, images, technical data and specifications
NAD M23
Image source — © NAD
What is it?
Ask AI to scan specialized sites and forums, evaluate the impressions of using the product, its advantages and disadvantages and get a summary.
Specifications
Model name
M23
Input sensitivity (mV)
N/A
Input impedance (balanced) (Ω)
56 000
Input impedance (single-ended) (Ω)
56 000
Output impedance (balanced) (Ω)
N/A
Output impedance (single-ended) (Ω)
N/A
Max current (A)
N/A
Output power (8Ω) (W)
200
Output power (4Ω) (W)
380
Gain (dBu)
N/A
Frequency response low +/- 3dB (Hz)
20
Frequency response high +/- 3dB (Hz)
20 000
Signal to Noise Ratio (dB)
>127
Total Harmonic Distortion + Noise (0% global feedback) (%)
N/A
Total Harmonic Distortion + Noise (100% global feedback) (%)
<0.00069
Max power consumption (W)
N/A
Damping factor
>800
Dimensions (mm)
435 x 133 x 381
Weight (kg)
9.7
Official link
