Power amplifiers stereo — NAD M28
Description, images, technical data and specifications
NAD M28
Image source — © NAD
What is it?
Ask AI to scan specialized sites and forums, evaluate the impressions of using the product, its advantages and disadvantages and get a summary.
Specifications
Model name
M28
Input sensitivity (mV)
1300
Input impedance (balanced) (Ω)
47 000
Input impedance (single-ended) (Ω)
23 000
Output impedance (balanced) (Ω)
N/A
Output impedance (single-ended) (Ω)
N/A
Max current (A)
N/A
Output power (8Ω) (W)
220
Output power (4Ω) (W)
400
Gain (dBu)
N/A
Frequency response low +/- 3dB (Hz)
3
Frequency response high +/- 3dB (Hz)
100 000
Signal to Noise Ratio (dB)
>102
Total Harmonic Distortion + Noise (0% global feedback) (%)
N/A
Total Harmonic Distortion + Noise (100% global feedback) (%)
≤0.003
Max power consumption (W)
N/A
Damping factor
>750
Dimensions (mm)
435 x 156 x 380
Weight (kg)
21.2
Official link
More components
Power amplifiers stereo
NAD CI 980
The NAD CI 980 is an 8-channel amplifier for professional installations. Output power is 8 x 50 W, at 8 ohms / 2 x 120 W, at 8 ohms (bridge connection). The ability to work in 4 zones. Individual level adjustment for each zone. Removable Phoenix-type acoustic terminals. Brackets for mounting in a rack rack.
Power amplifiers stereo
NAD C 268
With balanced inputs, the C 268 is a natural choice for high-performance preamps and processors. These inputs have a trim control function, for matching with other components, or for two-amp connection to speakers. The through-line output allows you to add another power amplifier to the same channel for additional speakers or subwoofers. In addition, there is a bridge switch that turns the C 268 into a surprisingly powerful monoblock amplifier.
Power amplifiers stereo
NAD CI 8-120 DSP
Hypex UcD amplification modules are installed inside the thin case, delivering up to 120 Watts per channel in class D, while in bridge mode their power increases to 200 watts. However, at the same time, the number of channels is reduced by half. On the front panel there are LED indicators showing the number of active modules, as well as ventilation grilles that ensure heat dissipation from the output stages.
Power amplifiers stereo
NAD CI 8-150 DSP
The power is 150 watts for each of the eight channels, and in bridge mode, the device can output up to 365 watts for four channels. In addition to the analog and network inputs, the amplifier has optical and coaxial digital inputs. The device is built on Hyperx amplifier modules, network control and equalizer settings via a network interface are also provided.
Power amplifiers stereo
NAD C 298
The novelty's power is 185 watts for an 8 ohm load, and in bridge mode, the device is capable of delivering an incredible 620 watts for the same resistance load. A solid power supply provides enough current for reliable operation at a 4 Ohm load, at which the model outputs 340 watts of constant power and up to 570 watts of peak power.
