Streamers — Cary Audio DMS-700

Description, images, technical data and specifications

Cary Audio DMS-700
Image source — © Cary Audio

DACs with an R2R current output, which use simple current division on resistors with a sequential resistance ratio of 1:2:4:8 and so on, have been known since the birth of digital audio.

What is it?

Ask AI to scan specialized sites and forums, evaluate the impressions of using the product, its advantages and disadvantages and get a summary.

Specifications

  • Model name

    DMS-700

  • Has internal DAC

    Yes

  • DSD compatability

    Yes

  • Parameters

    up to 32 bit / 768 kHz and DSD512

  • DSP processing

    N/A

  • Frequency response low +/- 3dB (Hz)

    2

  • Frequency response high +/- 3dB (Hz)

    22 000

  • Gain (dBu)

    N/A

  • Input Impedance (balanced) (Ω)

    N/A

  • Input Impedance (single-ended) (Ω)

    N/A

  • Output Impedance (balanced) (Ω)

    440

  • Output Impedance (single-ended) (Ω)

    220

  • Analog outputs level (balanced) (V)

    3

  • Analog outputs level (single-ended) (V)

    3

  • Signal to Noise Ratio (dB)

    127

  • Total Harmonic Distortion + Noise (% at 22 kHz)

    0.0001

  • Dimensions (mm)

    95 x 438 x 413

  • Weight (kg)

    12.7

  • Official link

    https://caryaudio.com/products/dms-700-network-audio-player/

Cary Audio DMS-800 PV

Cary Audio DMS-650

More components

  • DMS-650

    Streamers

    Cary Audio DMS-650

    The DMS-650 is a player with a new design, where dynamic elements are located on the right side of the front panel. The output stage is based on a high-resolution digital audio circuit. The basis of the scheme was the AKM AK4497EQ DAC. Users will be able to choose a player in black or silver trim.

  • DMS-800 PV

    Streamers

    Cary Audio DMS-800 PV

    The dual mono design also allows for a fully balanced differential circuit with 8 channels of digital-to-analog conversion (4-channel AK4499EQ chips). The DMS-800PV uses two DSP (digital signal processing) service circuits, a superstable Crystek clock generator, 14 stabilized power lines for digital and utility circuits, two stabilized power lines for analog output stages, and many other large and small parts that work for sound quality.
