DACs — Gold Note DS-1000 EVO
Description, images, technical data and specifications
Gold Note DS-1000 EVO
Image source — © Gold Note
The DS-1000 EVO Line is the most advanced streaming DAC ever created by Gold Note, combining advanced digital—to-analog conversion technology with unique know-how in delivering superior sound quality, or, as we call it, Italian sound.
Specifications
Model name
DS-1000 EVO
Conversion type
N/A
Engine
AKM AK4493
DSD compatability
Yes
Parameters
up to 32bit/384kHz and DSD512
Frequency response low +/- 3dB (Hz)
20
Frequency response high +/- 3dB (Hz)
20 000
Gain (dBu)
N/A
Output Level (balanced) (V)
N/A
Output Level (single-ended) (V)
N/A
Input Impedance (balanced) (Ω)
N/A
Input Impedance (single-ended) (Ω)
N/A
Output Impedance (balanced) (Ω)
100
Output Impedance (single-ended) (Ω)
50
Analog outputs
N/A
Signal to Noise Ratio (dB)
125
Total Harmonic Distortion + Noise (% at 22 kHz)
0.001
Dimensions (mm)
430 x 135 x 375
Weight (kg)
3.75
