TOPPING Centaurus DAC
Image source — © TOPPING
TOPPING has introduced the new Centaurus digital-to-analog converter, which uses R2R architecture and is implemented in a fully balanced architecture, which includes eight resistor board (developed jointly with HOLO Audio).
The key aspect of this solution is the processing of both DSD and PCM streams. Vector Step Resistance Network technology is specially used for decoding DSD, while the traditional R2R scheme is used for processing PCM. The process is controlled by a CPLD chip, which guarantees accurate decoding of musical material.
The key aspect of this solution is the processing of both DSD and PCM streams. Vector Step Resistance Network technology is specially used for decoding DSD, while the traditional R2R scheme is used for processing PCM. The process is controlled by a CPLD chip, which guarantees accurate decoding of musical material.
Specifications
Model name
Centaurus DAC
Conversion type
R2R
Engine
Vector Step Resistance Network + R2R
DSD compatability
Yes
Parameters
up to 32/768 and DSD512
Frequency response low +/- 3dB (Hz)
20
Frequency response high +/- 3dB (Hz)
40000
Gain (dBu)
N/A
Output Level (balanced) (V)
N/A
Output Level (single-ended) (V)
N/A
Input Impedance (balanced) (Ω)
N/A
Input Impedance (single-ended) (Ω)
N/A
Output Impedance (balanced) (Ω)
N/A
Output Impedance (single-ended) (Ω)
N/A
Analog outputs
2.1 - 2.6
Signal to Noise Ratio (dB)
126
Total Harmonic Distortion + Noise (% at 22 kHz)
0.0005
Dimensions (mm)
N/A
Weight (kg)
N/A
