DACs — TOPPING DX9 Discrete
Description, images, technical data and specifications
TOPPING DX9 Discrete
Image source — © TOPPING
The Topping DX9 Discrete headphone amplifier DAC is equipped with a fully balanced hybrid relay volume control, providing ultra-precise level setting with minimal signal degradation. The correct channel balance is maintained at any volume level, which allows you to work equally well with highly sensitive in-ear headphones, and with low-sensitivity/high-resistance full-size models.
Specifications
Model name
DX9 Discrete
Conversion type
N/A
Engine
Qualcomm QCC5125
DSD compatability
Yes
Parameters
up to 32 bit / 768 kHz and DSD512
Frequency response low +/- 3dB (Hz)
20
Frequency response high +/- 3dB (Hz)
40 000
Gain (dBu)
N/A
Output Level (balanced) (V)
5.2
Output Level (single-ended) (V)
2.5
Input Impedance (balanced) (Ω)
N/A
Input Impedance (single-ended) (Ω)
N/A
Output Impedance (balanced) (Ω)
N/A
Output Impedance (single-ended) (Ω)
N/A
Analog outputs
N/A
Signal to Noise Ratio (dB)
131 (XLR) + 128 (RCA)
Total Harmonic Distortion + Noise (% at 22 kHz)
0,00006% (XLR) + 0,00007% (RCA)
Dimensions (mm)
N/A
Weight (kg)
N/A
