Power amplifiers stereo — Chord ULTIMA 5
Description, images, technical data and specifications
Chord ULTIMA 5
Image source — © Chord
The output stage uses 32 MOSFET field-effect transistors in each channel, double-crystal, with a horizontal structure. These transistors are developed by Chord Electronics and are manufactured exclusively for ULTIMA amplifiers by a British manufacturer of microelectronic devices.
Specifications
Model name
ULTIMA 5
Input sensitivity (mV)
N/A
Input impedance (balanced) (Ω)
N/A
Input impedance (single-ended) (Ω)
N/A
Output impedance (balanced) (Ω)
N/A
Output impedance (single-ended) (Ω)
N/A
Max current (A)
N/A
Output power (8Ω) (W)
300
Output power (4Ω) (W)
500
Gain (dBu)
30
Frequency response low +/- 3dB (Hz)
0.5
Frequency response high +/- 3dB (Hz)
100 000
Signal to Noise Ratio (dB)
N/A
Total Harmonic Distortion + Noise (0% global feedback) (%)
N/A
Total Harmonic Distortion + Noise (100% global feedback) (%)
0.005
Max power consumption (W)
2000
Damping factor
N/A
Dimensions (mm)
180 x 480 x 36
Weight (kg)
22.4
Official link
