Power amplifiers mono — Vitus Audio MP-M201 MK.II

Description, images, technical data and specifications

Vitus Audio MP-M201 MK.II
Image source — © Vitus Audio

MP-M201 MkII is specifically designed for complex dual-gain speaker systems and solves typical problems found in such systems, including external active crossovers and special bass amplification. When you think about the uncompromising approach we take to each project, you will quickly understand why this amplifier took years of painstaking and complex development to create something truly impressive.

What is it?

Ask AI to scan specialized sites and forums, evaluate the impressions of using the product, its advantages and disadvantages and get a summary.

Specifications

  • Model name

    MP-M201 MK.II

  • Input sensitivity (mV)

    2000

  • Input impedance (balanced) (Ω)

    10 000

  • Input impedance (single-ended) (Ω)

    N/A

  • Output impedance (balanced) (Ω)

    N/A

  • Output impedance (single-ended) (Ω)

    0.075

  • Max current (A)

    N/A

  • Output power (8Ω) (W)

    300

  • Output power (4Ω) (W)

    500

  • Gain (dBu)

    N/A

  • Frequency response low +/- 3dB (Hz)

    N/A

  • Frequency response high +/- 3dB (Hz)

    800 000

  • Signal to Noise Ratio (dB)

    >130

  • Total Harmonic Distortion + Noise (0% global feedback) (%)

    N/A

  • Total Harmonic Distortion + Noise (100% global feedback) (%)

    <0.01

  • Max power consumption (W)

    N/A

  • Damping factor

    N/A

  • Dimensions (mm)

    270 × 435 × 610

  • Weight (kg)

    65

  • Official link

    https://www.vitusaudio.com/products/mp-m201-mk-ii/
