Power amplifiers mono — Vitus Audio SM-103 MK.II
Description, images, technical data and specifications
Vitus Audio SM-103 MK.II
Image source — © Vitus Audio
Combined with the special connection of each input stage, the SM-103 MKll provides an ultra-linear frequency response. A truly balanced design combined with a locally shunt-controlled power supply provides excellent signal-to-noise ratio, allowing you to identify every micro detail in the recordings.
Specifications
Model name
SM-103 MK.II
Input sensitivity (mV)
2000
Input impedance (balanced) (Ω)
10 000
Input impedance (single-ended) (Ω)
10 000
Output impedance (balanced) (Ω)
N/A
Output impedance (single-ended) (Ω)
0.075
Max current (A)
N/A
Output power (8Ω) (W)
100
Output power (4Ω) (W)
200
Gain (dBu)
N/A
Frequency response low +/- 3dB (Hz)
N/A
Frequency response high +/- 3dB (Hz)
800 000
Signal to Noise Ratio (dB)
>100
Total Harmonic Distortion + Noise (0% global feedback) (%)
N/A
Total Harmonic Distortion + Noise (100% global feedback) (%)
<0.01
Max power consumption (W)
N/A
Damping factor
N/A
Dimensions (mm)
310 × 435 × 601
Weight (kg)
75
Official link
