Audio-Technica AT-OC9XSL
Image source — © Audio-Technica

Audio‑Technica AT‑OC9XSL is a high—end MC pickup, the development of the iconic OC9 series. It is distinguished by its refined presentation: it reveals the nuances of recordings, preserves the naturalness of timbres and the integrity of the musical picture. The black and gold case highlights the premium status. The model is appreciated for its confident track following and balanced, detailed sound — the choice of audiophiles who value vibrant, rich vinyl.

Specifications

  • Model name

    AT-OC9XSL

  • Type

    MC

  • Stylus

    Nude rectangular shank

  • Body

    N/A

  • Cantilever

    0.28 mm Ø nude boron

  • Coils

    N/A

  • Output voltage (mV@5cm/sec)

    0.4

  • Frequency response low +/- 3dB (Hz)

    20

  • Frequency response high +/- 3dB (Hz)

    50 000

  • Internal impedance (Ohm)

    12

  • Channel separation (dB / 1,000 Hz)

    28

  • Compliance (×10-6cm/dyne at 100Hz)

    18

  • Recommended load (Ohm)

    >100

  • Recommended tonearms

    N/A

  • Weight (g)

    7.6
