Musical Fidelity M3X DAC
Image source — © Musical Fidelity
The model uses many solutions developed for the older M6 x model, providing functionality and sound quality similar to the components of the M6 series, but at a more affordable price. The Musical Fidelity M3x DAC is based on Burr Brown PCM1795 DAC chips and the Burr Brown SRC4392 sampling frequency converter, which increases the parameters of the digital signal to 24 bits/192 kHz, providing playback of digital content with minimal distortion.
Specifications
Model name
M3X DAC
Conversion type
N/A
Engine
PCM1795
DSD compatability
Yes
Parameters
up to 32 bit / 192kHz and DSD512
Frequency response low +/- 3dB (Hz)
20
Frequency response high +/- 3dB (Hz)
20 000
Gain (dBu)
N/A
Output Level (balanced) (V)
N/A
Output Level (single-ended) (V)
N/A
Input Impedance (balanced) (Ω)
N/A
Input Impedance (single-ended) (Ω)
N/A
Output Impedance (balanced) (Ω)
N/A
Output Impedance (single-ended) (Ω)
N/A
Analog outputs
N/A
Signal to Noise Ratio (dB)
>107
Total Harmonic Distortion + Noise (% at 22 kHz)
< 0,005
Dimensions (mm)
440 x 100 x 363
Weight (kg)
6.8
