DACs — SMSL D200
Description, images, technical data and specifications
SMSL D200
Image source — © SMSL
The SMSL D200 external DAC is based on the BD34352EKV chipset, which provides exceptional resolution and clarity, and the advanced XMOS XU316 third-generation 16-core USB processor. The new product supports decoding of digital streams in PCM format with a resolution up to 32 bits / 768 kHz and DSD up to DSD512.
Specifications
Model name
D200
Conversion type
N/A
Engine
N/A
DSD compatability
Yes
Parameters
up to 32 bit / 768 kHz and DSD512
Frequency response low +/- 3dB (Hz)
N/A
Frequency response high +/- 3dB (Hz)
N/A
Gain (dBu)
N/A
Output Level (balanced) (V)
5
Output Level (single-ended) (V)
2.5
Input Impedance (balanced) (Ω)
N/A
Input Impedance (single-ended) (Ω)
N/A
Output Impedance (balanced) (Ω)
N/A
Output Impedance (single-ended) (Ω)
N/A
Analog outputs
N/A
Signal to Noise Ratio (dB)
121 (RCA) + 123 (XLR)
Total Harmonic Distortion + Noise (% at 22 kHz)
0.00019
Dimensions (mm)
200 x 47.9 x 197.9
Weight (kg)
1.214
