DACs — WADAX Atlantis REFERENCE DAC

Description, images, technical data and specifications

WADAX Atlantis REFERENCE DAC
Image source — © WADAX

Atlantis REFERENCE DAC is unique - the clock circuitry, PSU topology and distributed regulation, the implementation of the musIC feed-forward error correction technology. the totally independent, dual-Mono DAC and analog circuitry. the fully modular construction, left and right channel power supplies, the mechanical vibration management incorporated in the chassis construction – the surface of a product that contains 23 printed circuit boards, 10 independent, purpose-wound power transformers and over 5,500 discrete parts.

Specifications

  • Model name

    Atlantis REFERENCE DAC

  • Conversion type

    N/A

  • Engine

    N/A

  • DSD compatability

    Yes

  • Parameters

    N/A

  • Frequency response low +/- 3dB (Hz)

    N/A

  • Frequency response high +/- 3dB (Hz)

    N/A

  • Gain (dBu)

    N/A

  • Output Level (balanced) (V)

    1 - 4

  • Output Level (single-ended) (V)

    1 - 4

  • Input Impedance (balanced) (Ω)

    N/A

  • Input Impedance (single-ended) (Ω)

    N/A

  • Output Impedance (balanced) (Ω)

    0.4 - 600

  • Output Impedance (single-ended) (Ω)

    0.4 - 600

  • Analog outputs

    N/A

  • Signal to Noise Ratio (dB)

    N/A

  • Total Harmonic Distortion + Noise (% at 22 kHz)

    N/A

  • Dimensions (mm)

    N/A

  • Weight (kg)

    N/A

  • Official link

    https://wadax.eu/reference/
