Power amplifiers stereo — Luxman M-10X

Name: M-10X
Brand: Luxman
Rating: 100 (1 reviews)

Description, images, technical data and specifications

Luxman M-10X
Image source — © Luxman

The amplifier weighs 48.4 kg and is capable of delivering 2 × 150 watts with a speaker resistance of 8 ohms and 2 × 1,200 watts with a resistance of 1 ohm. It is reported about the "stadium" single-channel 2.4 kW at 2 ohms in BTL mode. The high damping coefficient helps to cope with even the most difficult speakers.

What is it?

Ask AI to scan specialized sites and forums, evaluate the impressions of using the product, its advantages and disadvantages and get a summary.

Specifications

Model name
M-10X
Input sensitivity (mV)
1240
Input impedance (balanced) (Ω)
28 000
Input impedance (single-ended) (Ω)
51 000
Output impedance (balanced) (Ω)
N/A
Output impedance (single-ended) (Ω)
N/A
Max current (A)
N/A
Output power (8Ω) (W)
150
Output power (4Ω) (W)
300
Gain (dBu)
29
Frequency response low +/- 3dB (Hz)
1
Frequency response high +/- 3dB (Hz)
130 000
Signal to Noise Ratio (dB)
117
Total Harmonic Distortion + Noise (0% global feedback) (%)
N/A
Total Harmonic Distortion + Noise (100% global feedback) (%)
0.04
Max power consumption (W)
540
Damping factor
600
Dimensions (mm)
440 x 224 x 488
Weight (kg)
48.4
Official link
https://www.luxman.com/product/detail.php?id=41
