Power amplifiers mono — Dan D'Agostino Momentum Z
Description, images, technical data and specifications
Dan D'Agostino Momentum Z
Image source — © Dan D'Agostino
The specified performance figures are impressive: 500 W into 8 ohms, doubling to 1,000 W into 4 ohms and 2,000 W into 2 ohms. This places the Momentum Z among the most powerful home audio amplifiers, but sheer power is only part of the story. The main focus lies in how that power is controlled. The Kinetic Drive Regulator uses a hybrid of MOSFET and bipolar transistors to stabilise the amplifier against fluctuations in the mains supply and varying speaker loads, reducing noise, lowering distortion, and ensuring more consistent control of demanding loudspeakers.
Specifications
Model name
Momentum Z
Input sensitivity (mV)
N/A
Input impedance (balanced) (Ω)
1000000
Input impedance (single-ended) (Ω)
N/A
Output impedance (balanced) (Ω)
0.05
Output impedance (single-ended) (Ω)
N/A
Max current (A)
N/A
Output power (8Ω) (W)
500
Output power (4Ω) (W)
1000
Gain (dBu)
N/A
Frequency response low +/- 3dB (Hz)
1
Frequency response high +/- 3dB (Hz)
200000
Signal to Noise Ratio (dB)
N/A
Total Harmonic Distortion + Noise (0% global feedback) (%)
N/A
Total Harmonic Distortion + Noise (100% global feedback) (%)
N/A
Max power consumption (W)
N/A
Damping factor
N/A
Dimensions (mm)
320 x 130 x 540
Weight (kg)
45
