Power amplifiers mono — Electrocompaniet AW 800 M
Description, images, technical data and specifications
Electrocompaniet AW 800 M
Image source — © Electrocompaniet
A distinctive feature of the new amplifier is its ability to work equally successfully in both stereo and mono mode. In the first case, its output power is 300 Watts per channel at 8 ohms, in the second it increases to 800 watts with the same resistance load and reaches a monstrous 1,500 watts when operating at 4 ohms.
Specifications
Model name
AW 800 M
Input sensitivity (mV)
N/A
Input impedance (balanced) (Ω)
330 000
Input impedance (single-ended) (Ω)
330 000
Output impedance (balanced) (Ω)
N/A
Output impedance (single-ended) (Ω)
N/A
Max current (A)
N/A
Output power (8Ω) (W)
300
Output power (4Ω) (W)
600
Gain (dBu)
35
Frequency response low +/- 3dB (Hz)
0.5
Frequency response high +/- 3dB (Hz)
1 100 000
Signal to Noise Ratio (dB)
122
Total Harmonic Distortion + Noise (0% global feedback) (%)
N/A
Total Harmonic Distortion + Noise (100% global feedback) (%)
0.0006
Max power consumption (W)
N/A
Damping factor
>1000
Dimensions (mm)
406 × 488 × 292
Weight (kg)
55
Official link
