Power amplifiers mono — Line Magnetic AS-125PP

Description, images, technical data and specifications

Line Magnetic AS-125PP
Image source — © Line Magnetic

The Line Magnetic AS-125PP is a refined audio component designed for passionate music lovers who appreciate natural expression and an immersive listening experience. Its elegant construction reflects the brand’s dedication to traditional craftsmanship, combining timeless aesthetics with an engaging and emotionally captivating character.

Specifications

  • Model name

    AS-125PP

  • Input sensitivity (mV)

    250

  • Input impedance (balanced) (Ω)

    N/A

  • Input impedance (single-ended) (Ω)

    100 000

  • Output impedance (balanced) (Ω)

    N/A

  • Output impedance (single-ended) (Ω)

    N/A

  • Max current (A)

    N/A

  • Output power (8Ω) (W)

    60

  • Output power (4Ω) (W)

    N/A

  • Gain (dBu)

    51/63

  • Frequency response low +/- 3dB (Hz)

    10

  • Frequency response high +/- 3dB (Hz)

    70 000

  • Signal to Noise Ratio (dB)

    88

  • Total Harmonic Distortion + Noise (0% global feedback) (%)

    N/A

  • Total Harmonic Distortion + Noise (100% global feedback) (%)

    1

  • Max power consumption (W)

    N/A

  • Damping factor

    N/A

  • Dimensions (mm)

    480 x 275 x 490

  • Weight (kg)

    43

  • Official link

    https://line-magnetic.eu/collections/all
