Power amplifiers mono — Line Magnetic AM-3 Mono
Description, images, technical data and specifications
Line Magnetic AM-3 Mono
Image source — © Line Magnetic
The 300B (push-pull) monoblock tube power amplifier delivers 15 watts at 4/8/16 ohms, features clear, rich sound, low distortion (0.8% at 15 watts), high input sensitivity (800 mV) and vintage design.
Specifications
Model name
AM-3 Mono
Input sensitivity (mV)
800
Input impedance (balanced) (Ω)
100 000
Input impedance (single-ended) (Ω)
100 000
Output impedance (balanced) (Ω)
N/A
Output impedance (single-ended) (Ω)
N/A
Max current (A)
N/A
Output power (8Ω) (W)
15
Output power (4Ω) (W)
15
Gain (dBu)
N/A
Frequency response low +/- 3dB (Hz)
20
Frequency response high +/- 3dB (Hz)
20 000
Signal to Noise Ratio (dB)
N/A
Total Harmonic Distortion + Noise (0% global feedback) (%)
N/A
Total Harmonic Distortion + Noise (100% global feedback) (%)
0.8
Max power consumption (W)
N/A
Damping factor
N/A
Dimensions (mm)
N/A
Weight (kg)
N/A
Official link
