Power amplifiers mono — Riviera Audio Labs AFM70
Description, images, technical data and specifications
Riviera Audio Labs AFM70
Image source — © Riviera Audio Labs
The Riviera Audio AFM70 operates in Class A and is capable of delivering 70 watts of power when operating on a load with a nominal resistance of 8 ohms. The pre-stage of the monoblock uses a vacuum lamp, and the output stage is built on semiconductors. Thus, a hybrid concept is implemented in the Riviera Audio AFM70.
Specifications
Model name
AFM70
Input sensitivity (mV)
220mVrms for 1W/8 ohm (2.83Vrms); 1.87Vrms for 70W/8 ohm (24Vrms)
Input impedance (balanced) (Ω)
47 000
Input impedance (single-ended) (Ω)
47 000
Output impedance (balanced) (Ω)
N/A
Output impedance (single-ended) (Ω)
N/A
Max current (A)
N/A
Output power (8Ω) (W)
70
Output power (4Ω) (W)
N/A
Gain (dBu)
22
Frequency response low +/- 3dB (Hz)
N/A
Frequency response high +/- 3dB (Hz)
N/A
Signal to Noise Ratio (dB)
N/A
Total Harmonic Distortion + Noise (0% global feedback) (%)
N/A
Total Harmonic Distortion + Noise (100% global feedback) (%)
N/A
Max power consumption (W)
N/A
Damping factor
N/A
Dimensions (mm)
340 × 485 × 195
Weight (kg)
30
