Integrated amplifiers — Vincent SV-237MKII
Description, images, technical data and specifications
Vincent SV-237MKII
Image source — © Vincent
The SV-237 MK II uses hybrid amplification technology. For Vincent, this solution means "the best of both worlds." Two 6N1P lamps operate in the pre-amplification section, giving the sound naturalness and warmth, while the power amplifier section uses 4 transistors, providing excellent dynamics and output power of up to 250 Watts (RMS) per channel.
Specifications
Model name
SV-237MKI
Type
Integrated Amplifier with DAC
Analog inputs (balanced)
N/A
Analog inputs (single-ended)
3
Input sensitivity (mV)
300
Input impedance (balanced) (Ω)
N/A
Input impedance (single-ended) (Ω)
47 000
Output impedance (balanced) (Ω)
N/A
Output impedance (single-ended) (Ω)
N/A
D/A conversion
Yes
Phono MM/MC current-sensing input impedance (Ω)
N/A
Output power (8Ω) (W)
150
Output power (4Ω) (W)
250
Gain (dBu)
N/A
Frequency response low +/- 3dB (Hz)
20
Frequency response high +/- 3dB (Hz)
20 000
Signal to Noise Ratio (dB)
>90
Total Harmonic Distortion + Noise (%)
<0.1
Damping factor
N/A
Dimensions (mm)
430 x 152 x 435
Weight (kg)
20.4
Official link
