Integrated amplifiers — Line Magnetic LM-Mini 84IA

Description, images, technical data and specifications

Line Magnetic LM-Mini 84IA
Image source — © Line Magnetic

Line Magnetic Audio LM‑Mini 84IA is a compact tube integrated amplifier in a retro style; it combines hand‑built construction, spot‑welding, and premium components, delivering a warm, detailed sound and performing equally well with both headphones and sensitive loudspeakers.

Specifications

  • Model name

    LM-Mini 84IA

  • Type

    Tube Integrated Amplifier

  • Analog inputs (balanced)

    N/A

  • Analog inputs (single-ended)

    1

  • Input sensitivity (mV)

    240

  • Input impedance (balanced) (Ω)

    N/A

  • Input impedance (single-ended) (Ω)

    100 000

  • Output impedance (balanced) (Ω)

    N/A

  • Output impedance (single-ended) (Ω)

    N/A

  • D/A conversion

    N/A

  • Phono MM/MC current-sensing input impedance (Ω)

    N/A

  • Output power (8Ω) (W)

    3 + 3

  • Output power (4Ω) (W)

    N/A

  • Gain (dBu)

    N/A

  • Frequency response low +/- 3dB (Hz)

    20

  • Frequency response high +/- 3dB (Hz)

    51 000

  • Signal to Noise Ratio (dB)

    87

  • Total Harmonic Distortion + Noise (%)

    1

  • Damping factor

    N/A

  • Dimensions (mm)

    175 x 132 x 190

  • Weight (kg)

    5

  • Official link

    https://line-magnetic.eu/collections/all
