Integrated amplifiers — Dartzeel LHC-208
Description, images, technical data and specifications
Dartzeel LHC-208
Image source — © Dartzeel
LHC-208 integrated amplifier with integrated network streamer and USB DAC-A with support for formats up to 24-bit / 384 PCM and 4 x DSD from the NAS server. The amplifier is equipped with a high-quality digital-to-analog converter, a progressive digital part (which includes an ultra-stable darTZeel Smart Clock) and, in addition to 4 analog and 6 digital audio inputs, an Ethernet port for connecting to a local network via a router.
Specifications
Model name
LHC-208
Type
Integrated Amplifier with Streamer and USB-DAC
Analog inputs (balanced)
N/A
Analog inputs (single-ended)
3
Input sensitivity (mV)
N/A
Input impedance (balanced) (Ω)
N/A
Input impedance (single-ended) (Ω)
30 000
Output impedance (balanced) (Ω)
N/A
Output impedance (single-ended) (Ω)
N/A
D/A conversion
N/A
Phono MM/MC current-sensing input impedance (Ω)
N/A
Output power (8Ω) (W)
200
Output power (4Ω) (W)
300
Gain (dBu)
N/A
Frequency response low +/- 3dB (Hz)
7
Frequency response high +/- 3dB (Hz)
170 000
Signal to Noise Ratio (dB)
>105
Total Harmonic Distortion + Noise (%)
<1
Damping factor
N/A
Dimensions (mm)
440 x 350 x 130
Weight (kg)
16
Official link
