Integrated amplifiers — Yamaha A-S801

Specifications

• Model name

  A-S801

• Type

  Integrated Amplifier

• Analog inputs (balanced)

  N/A

• Analog inputs (single-ended)

  5

• Input sensitivity (mV)

  N/A

• Input impedance (balanced) (Ω)

  N/A

• Input impedance (single-ended) (Ω)

  47 000

• Output impedance (balanced) (Ω)

  N/A

• Output impedance (single-ended) (Ω)

  N/A

• D/A conversion

  Yes

• Phono MM/MC current-sensing input impedance (Ω)

  N/A

• Output power (8Ω) (W)

  100

• Output power (4Ω) (W)

  160

• Gain (dBu)

  N/A

• Frequency response low +/- 3dB (Hz)

  10

• Frequency response high +/- 3dB (Hz)

  100 000

• Signal to Noise Ratio (dB)

  100

• Total Harmonic Distortion + Noise (%)

  0.019

• Damping factor

  240

• Dimensions (mm)

  435x152x387

• Weight (kg)

  12.1

• Official link

  http://www.yamaha-es.com/en/products/audio_visual/hifi_components/a-s801/specs.html
