Integrated amplifiers — Yamaha A-S2200

Name: A-S2200
Brand: Yamaha
Rating: 100 (1 reviews)

Description, images, technical data and specifications

Yamaha A-S2200
Image source — © Yamaha

The Yamaha AS 2200 uses fully balanced circuitry and uses the highest-end components. There is also balanced switching, as well as a built-in phono corrector for both movable magnet (MM) and movable coil (MC) heads. Developing up to 160 Watts in each channel when operating on a load with a nominal resistance of 4 ohms, the amplifier demonstrates a damping coefficient exceeding 250.

Specifications

Model name
A-S2200
Type
Integrated Amplifier with Phono
Analog inputs (balanced)
N/A
Analog inputs (single-ended)
N/A
Input sensitivity (mV)
N/A
Input impedance (balanced) (Ω)
100 000
Input impedance (single-ended) (Ω)
47 000
Output impedance (balanced) (Ω)
N/A
Output impedance (single-ended) (Ω)
N/A
D/A conversion
N/A
Phono MM/MC current-sensing input impedance (Ω)
47 000 (MM) + 50 (MC)
Output power (8Ω) (W)
90
Output power (4Ω) (W)
150
Gain (dBu)
N/A
Frequency response low +/- 3dB (Hz)
5
Frequency response high +/- 3dB (Hz)
100 000
Signal to Noise Ratio (dB)
114
Total Harmonic Distortion + Noise (%)
0.02
Damping factor
≧ 250
Dimensions (mm)
435×157×463
Weight (kg)
22.7
Official link
https://europe.yamaha.com/en/products/audio_visual/hifi_components/a-s2200/index.html
