JM Reynaud

JM-Reynaud Lucia is a compact model of bookshelf acoustics from the French manufacturer Jean—Marie Reynaud with an input power of 200 watts.

The JM Reynaud Folia Jubilee is a compact two—lane model. The tweeter is equipped with a soft dome with a diameter of 25 mm, a boomer membrane made of paper measuring 13 cm. Sensitivity — 86 dB/2 V/1 m, bandwidth — 60 Hz — 22 kHz, nominal/minimum resistance — 6/4 ohms.

The front panel of the model carries two drivers of the company's own production, the main midrange / woofer driver, measuring 17 cm, is mounted without a single screw using a through bolt mounted on the back wall. The tweeter is equipped with a soft dome with an impregnation diameter of 28 mm. The acoustic design is traditional for the company's products – four consecutive chambers ensure smooth and gradual absorption of back-radiation energy.

The JMR Luna is made in a 2.5-band concept, where the bass section works in an acoustic design with a transmission line, the slot port of which is located on the front panel of the case. The internal space of the column is divided by a multitude of partitions in such a way that there is not a single pair of parallel surfaces, which makes it possible to effectively deal with standing waves.

The low-frequency driver of this model with a diameter of 17 cm is equipped with a diffuser made of long-fiber cellulose with a special impregnation. The coil is wound with titanium wire, and the magnetic system uses double magnets to increase recoil. The squeaker has a woven dome with a diameter of 28 mm and is loaded onto a small aluminum waveguide. The magnetic system is based on neodymium.

The Cantabile Jubilee is an floorstanding speaker that offers a spacious, wide and deep sound stage with incredible spatial precision. The recommended amplifier power is 10-200 watts, sensitivity is 91 dB, resistance is 4 ohms, and the frequency range is 35-25,000 Hz.

The Cantabile Jubilee is an floorstanding speaker that offers a spacious, wide and deep sound stage with incredible spatial precision. The recommended amplifier power is 10-200 watts, sensitivity is 91 dB, resistance is 4 ohms, and the frequency range is 35-25,000 Hz.

ABSCISSE JUBILEE is a compact speaker system designed with the aim of creating a system with a wide frequency range that can be installed in medium—sized rooms with minimal restrictions on placement.

The JM ORFEO JUBILEE is a relatively compact, high—performance 2.5-band floorstanding speaker system with high tonal and energetic qualities.

Jean-Marie Reynaud ORFEOG RANDE is characterized by precise tonal balance, clear and dynamic sound pattern, and natural timbres. The model has improved dynamics and filters, used selected and paired components, as well as an exceptional tree.

The acoustic load is made in the form of four interconnected volumes that provide gradual absorption of the back radiation of the diffuser. The latter is equipped with a complex 18 cm diffuser consisting of 7 layers of carbon fiber and polyesteresterketone. In the center there is a phase-leveling insert made of aluminum, the sound coil is wound on a fiberglass frame. The original AST ribbon tweeter is responsible for high frequencies, switched on at 1200 Hz in the first order – 12 dB per octave.
