Phonostages — NAD PP 4
Description, images, technical data and specifications
NAD PP 4
Image source — © NAD
PP 4 Digital Phono/USB Preamp allows you to digitize your favorite vinyl record collections. The device is equipped with low-noise inputs for both MM (with a movable magnet) and MC (with a movable coil) types for a wide variety of pickups, as well as a line input for cassette transmission. PP 4 includes Studio Lite software for copying and recording records. The Phono-to-USB PP 4 preamp offers a complete software and hardware solution with exceptional flexibility for recording from LP or cassette.
Specifications
Model name
PP 4
Inputs (balanced)
N/A
Inputs (single-ended)
1 + 2 (Phono)
MC current-sensing input impedance (Ω)
N/A
MM/MC voltage input impedance (Ω)
47 000 (MM) + 100 (MC)
Output impedance (Ω)
N/A
Gain (dB)
N/A
Playback EQ curves accuracy (dB)
N/A
Frequency response low +/- 3dB (Hz)
20
Frequency response high +/- 3dB (Hz)
20 000
Total Harmonic Distortion + Noise (%)
<0.03
Dimensions (mm)
135 x 49 x 72
Weight (kg)
N/A
