Musical Fidelity NU-VISTA VINYL 2
Image source — © Musical Fidelity

Musical Fidelity Nu-Vista Vinyl 2 is distinguished by the use of miniature vacuum tubes in the circuit. However, in this case they are used only in the output stage, the correction circuits are made on transistors, while three curves are supported – the classic RIAA, as well as the historical DECCA and Columbia.

Specifications

  • Model name

    NU-VISTA VINYL 2

  • Inputs (balanced)

    2

  • Inputs (single-ended)

    2

  • MC current-sensing input impedance (Ω)

    N/A

  • MM/MC voltage input impedance (Ω)

    47 000 (MM), 5 - 47 000 (MC)

  • Output impedance (Ω)

    N/A

  • Gain (dB)

    40dB, 43dB, 46dB, 49db (MM) + 60dB, 63dB, 66dB, 69dB (MC)

  • Playback EQ curves accuracy (dB)

    N/A

  • Frequency response low +/- 3dB (Hz)

    N/A

  • Frequency response high +/- 3dB (Hz)

    N/A

  • Total Harmonic Distortion + Noise (%)

    <0.005 (MM), <0.008 (MC)

  • Dimensions (mm)

    483 x 188 x 510

  • Weight (kg)

    22

  • Official link

    https://www.musicalfidelity.com/products/nu-vista/nu-vista-vinyl-2
