Ortofon MC 90X MC
Image source — © Ortofon
Equipped with Ortofon's proprietary Field Stabilizing Element (FSE) and Wide Range Damping (WRD) systems, the MC 90X cartridge delivers precise groove tracking and an extended frequency range. The WRD system uses a platinum disc between two rubber dampers, which optimizes resonance control and ensures linearity of the frequency response.
Specifications
Model name
MC 90X MC
Type
MC
Stylus
Ortofon Replicant 100 diamond
Body
N/A
Cantilever
Boron
Coils
Aucurum (Gold-plated 6NX OFC)
Output voltage (mV@5cm/sec)
0.25
Frequency response low +/- 3dB (Hz)
20
Frequency response high +/- 3dB (Hz)
20000
Internal impedance (Ohm)
4
Channel separation (dB / 1,000 Hz)
28
Compliance (×10-6cm/dyne at 100Hz)
11
Recommended load (Ohm)
> 10
Recommended tonearms
Medium
Weight (g)
9.5
Official link
