Cartidges — Ortofon SPU Royal N
Description, images, technical data and specifications
Ortofon SPU Royal N
Image source — © Ortofon
Specifications
Model name
SPU Royal N
Type
MC
Stylus
Nude Ortofon Replicant 100
Body
N/A
Cantilever
N/A
Coils
Goldplated silver
Output voltage (mV@5cm/sec)
0.2
Frequency response low +/- 3dB (Hz)
20
Frequency response high +/- 3dB (Hz)
20 000
Internal impedance (Ohm)
7
Channel separation (dB / 1,000 Hz)
25
Compliance (×10-6cm/dyne at 100Hz)
8 µm/mN
Recommended load (Ohm)
100
Recommended tonearms
N/A
Weight (g)
13
Official link
