Streamers — Esoteric N-05XD

Description, images, technical data and specifications

Esoteric N-05XD
Image source — © Esoteric

The N-05 XD, Esoteric's first network DAC/preamp, is specifically designed to deliver superior sound quality in any system configuration that already has your favorite power amplifier, speakers, and headphones. Integrating a fully balanced circuit directly borrowed from the flagship Esoteric series, the N-05XD network player is equipped with a clean, dedicated linear power supply and a discrete DAC of its own design, which ensures that its preamp and headphone amplifier are able to clearly reproduce the full-fledged sound of the original recording wizard.

What is it?

Ask AI to scan specialized sites and forums, evaluate the impressions of using the product, its advantages and disadvantages and get a summary.

Specifications

  • Model name

    N-05XD

  • Has internal DAC

    Yes

  • DSD compatability

    Yes

  • Parameters

    up to 32 bit / 384 kHz and DSD22.5

  • DSP processing

    N/A

  • Frequency response low +/- 3dB (Hz)

    5

  • Frequency response high +/- 3dB (Hz)

    75 000

  • Gain (dBu)

    N/A

  • Input Impedance (balanced) (Ω)

    50

  • Input Impedance (single-ended) (Ω)

    25

  • Output Impedance (balanced) (Ω)

    220

  • Output Impedance (single-ended) (Ω)

    60

  • Analog outputs level (balanced) (V)

    N/A

  • Analog outputs level (single-ended) (V)

    N/A

  • Signal to Noise Ratio (dB)

    105

  • Total Harmonic Distortion + Noise (% at 22 kHz)

    0.0015

  • Dimensions (mm)

    445 × 131 × 377

  • Weight (kg)

    13.8

  • Official link

    https://www.esoteric.jp/en/product/n-05xd/top
