DACs — Luxman DA-250
Description, images, technical data and specifications
Luxman DA-250
Image source — © Luxman
The most interesting features of the Luxman DA-250 are its capabilities, which differ significantly from the DA-200 model. So the USB input supports the following parameters: PCM — 32, 44.1, 48, 88.2, 96, 176.4, 192 kHz with 16, 24, and 32 bits, DSD — 2.82 and 5.64 MHz (1 bit). The digital inputs are represented by one coaxial and two optical inputs with 24/192 support. There are optical and coaxial outputs.
Specifications
Model name
DA-250
Conversion type
N/A
Engine
N/A
DSD compatability
Yes
Parameters
up to 32 bit / 192 kHz and DSD 5.64 MHz
Frequency response low +/- 3dB (Hz)
2
Frequency response high +/- 3dB (Hz)
50 000
Gain (dBu)
N/A
Output Level (balanced) (V)
2.5
Output Level (single-ended) (V)
2.5
Input Impedance (balanced) (Ω)
N/A
Input Impedance (single-ended) (Ω)
N/A
Output Impedance (balanced) (Ω)
600
Output Impedance (single-ended) (Ω)
300
Analog outputs
N/A
Signal to Noise Ratio (dB)
118
Total Harmonic Distortion + Noise (% at 22 kHz)
0.001
Dimensions (mm)
364 x 81 x 279
Weight (kg)
5,4
Official link
