Soulution Audio 360 DAC
Image source — © Soulution Audio
With 4 digital inputs (SPDIF, AES/EBU, Network, USB) connection to a wide range of signal sources is provided. The powerful DSP converts all incoming digital music signals to DXD format, performs ZeroPhase processing and LEEDH volume control. In a monophonic configuration, digital-to-analog conversion of musical signals provides one chip per channel.
Specifications
Model name
360 DAC
Conversion type
N/A
Engine
N/A
DSD compatability
Yes
Parameters
up to 24 bit / 192kHz and DSD128
Frequency response low +/- 3dB (Hz)
0
Frequency response high +/- 3dB (Hz)
200 000
Gain (dBu)
N/A
Output Level (balanced) (V)
4
Output Level (single-ended) (V)
2
Input Impedance (balanced) (Ω)
N/A
Input Impedance (single-ended) (Ω)
N/A
Output Impedance (balanced) (Ω)
10
Output Impedance (single-ended) (Ω)
5
Analog outputs
N/A
Signal to Noise Ratio (dB)
N/A
Total Harmonic Distortion + Noise (% at 22 kHz)
< 0.0003
Dimensions (mm)
430 x 350 x 142
Weight (kg)
10
