Graham Audio LS5/9F
Image source — © Graham Audio

The Graham Audio C5/9f was developed by Derek Hughes based on the iconic BBC LS5/9 model, which was redesigned as a floor mount. Frequency response is extended by 5 Hz "down", additional case damping is added

Specifications

  • Model name

    LS5/9F

  • Frequency Response low +/- 3dB (Hz)

    40

  • Frequency Response high +/- 3dB (Hz)

    16 000

  • Sensitivity (dB at 1 W/1m)

    87

  • Impedance (Ohms)

    8

  • Power amplifier requirements (W)

    50 - 200

  • Has internal amplification

    N/A

  • Internal amplification power (W)

    N/A

  • Size (sm)

    35 × 105 × 37

  • Weight (kg)

    25

  • Official link

    https://www.grahamaudio.co.uk/loudspeakers/ls59f
