Headphones amplifiers — Schiit Audio MAGNI

Description, images, technical data and specifications

Schiit Audio MAGNI
Image source — © Schiit Audio

The Schiit Magni is a compact stationary headphone amplifier designed to work with a wide range of impedance (usually 16-600 ohms), with power up to 2.1 watts at 16 ohms and 130 MW at 600 ohms

Specifications

  • Model name

    MAGNI

  • Maximum Power, 32 Ohms (mW RMS per channel)

    2500

  • Maximum Power, 50 Ohms (mW RMS per channel)

    1500

  • Maximum Power, 300 Ohms (mW RMS per channel)

    415

  • Maximum Power, 600 Ohms (mW RMS per channel)

    220

  • Frequency response low +/- 3dB (Hz)

    N/A

  • Frequency response high +/- 3dB (Hz)

    N/A

  • Gain (dBu)

    0.3, 1 or 5

  • THD (% at 1V RMS, 300 ohms)

    <0.0003

  • Signal to Noise Ratio (dB)

    122

  • IMD (%, CCIR, 300 Ohms)

    110

  • Crosstalk (dB, 20Hz-20KHz, 300 Ohms)

    <80

  • Output Impedance (Ohms)

    N/A

  • Dimensions (mm)

    127 x 89 x 32

  • Weight (kg)

    450

  • Official link

    https://www.schiit.com/products/magni-unity
