Preamplifiers — McIntosh C2800

Description, images, technical data and specifications

McIntosh C2800
Image source — © McIntosh

The C2800 tube preamp is a masterpiece of audio sophistication and engineering precision. Designed for discerning audiophiles and music lovers, performance is woven into the very fabric of this audio treasure. The C2800 has proudly earned the name McIntosh. The C2800 is based on a methodically designed circuit based on electronic lamps. Using the latest technology to eliminate noise and distortion, the C2800 reduces them to negligible levels. Its four electronic lights, or lamps, provide a listening experience that exceeds expectations.

What is it?

Ask AI to scan specialized sites and forums, evaluate the impressions of using the product, its advantages and disadvantages and get a summary.

Specifications

  • Model name

    C2800

  • Analog inputs (balanced)

    3

  • Analog inputs (single-ended)

    4

  • Analog outputs (balanced)

    3

  • Analog outputs (single-ended)

    N/A

  • Gain (dBu)

    64

  • Input sensitivity (mV)

    900 (XLR) + 450 (RCA)

  • Output voltage (V)

    16 (XLR) + 8 (RCA)

  • Input impedance (balanced) (Ω)

    44 000

  • Input impedance (single-ended) (Ω)

    22 000

  • Output impedance (balanced) (Ω)

    N/A

  • Output impedance (single-ended) (Ω)

    N/A

  • Maximum output level (balanced) (dBu)

    N/A

  • Maximum output level (single-ended) (dBu)

    8

  • Volume control range (dBu)

    N/A

  • Frequency response low +/- 3dB (Hz)

    15

  • Frequency response high +/- 3dB (Hz)

    100 000

  • Signal to Noise Ratio (SNR, unweighted) (dB)

    100

  • Total Harmonic Distortion + Noise (THD+N) (%)

    0.08

  • Dimensions (mm)

    444.5 x 194 x 419

  • Weight (kg)

    12.5

  • Official link

    https://www.mcintoshlabs.com/products/preamplifiers/C2800
