Lyngdorf MXA-8400
Image source — © Lyngdorf
The Lyngdorf MXA-8400 multichannel amplifier will be an excellent partner for the company's MP-40 2.1 and MP-60 2.1 AV processors, which are capable of decoding up to sixteen channels for Dolby Atmos and DTS-X installations.
Specifications
Model name
MXA-8400
Input sensitivity (mV)
2000
Input impedance (balanced) (Ω)
10 000
Input impedance (single-ended) (Ω)
N/A
Output impedance (balanced) (Ω)
N/A
Output impedance (single-ended) (Ω)
N/A
Max current (A)
N/A
Output power (8Ω) (W)
200
Output power (4Ω) (W)
400
Gain (dBu)
26.1
Frequency response low +/- 3dB (Hz)
20
Frequency response high +/- 3dB (Hz)
20 000
Signal to Noise Ratio (dB)
128
Total Harmonic Distortion + Noise (0% global feedback) (%)
N/A
Total Harmonic Distortion + Noise (100% global feedback) (%)
0.001
Max power consumption (W)
29
Damping factor
>1200
Dimensions (mm)
450 x 145 x 349
Weight (kg)
10.3
