Power amplifiers stereo — McIntosh MC462

Description, images, technical data and specifications

McIntosh MC462
Image source — © McIntosh

The McIntosh MC462 uses the proprietary Quad Balanced circuit and Autoformer technology, its output power of 2 x 450 watts is absolutely load tolerant (the indicators do not change on any speakers with a resistance from 2 to 8 ohms). The dynamic range margin has been increased (the filter bandwidth has increased by one and a half times), the signal-to-noise ratio reaches 122 dB.

Specifications

  • Model name

    MC462

  • Input sensitivity (mV)

    N/A

  • Input impedance (balanced) (Ω)

    N/A

  • Input impedance (single-ended) (Ω)

    N/A

  • Output impedance (balanced) (Ω)

    N/A

  • Output impedance (single-ended) (Ω)

    N/A

  • Max current (A)

    N/A

  • Output power (8Ω) (W)

    2 x 450

  • Output power (4Ω) (W)

    2 x 450

  • Gain (dBu)

    N/A

  • Frequency response low +/- 3dB (Hz)

    20

  • Frequency response high +/- 3dB (Hz)

    20 000

  • Signal to Noise Ratio (dB)

    122

  • Total Harmonic Distortion + Noise (0% global feedback) (%)

    N/A

  • Total Harmonic Distortion + Noise (100% global feedback) (%)

    0.005

  • Max power consumption (W)

    N/A

  • Damping factor

    >40

  • Dimensions (mm)

    444.5 x 239.7 x 572

  • Weight (kg)

    52.3

  • Official link

    https://www.mcintoshlabs.com/products/amplifiers/MC462
