Circle Labs Audio M200
Image source — © Circle Labs Audio

The Circle Labs M200 is a powerful stereo amplifier that can also work as a monoblock. In stereo mode, it outputs 160 watts at 8 ohms and 300 watts at 4 ohms, and in monoblock mode, it outputs up to 600 watts at 8 ohms and 930 watts at 4 ohms.

What is it?

Ask AI to scan specialized sites and forums, evaluate the impressions of using the product, its advantages and disadvantages and get a summary.

Specifications

  • Model name

    M200

  • Input sensitivity (mV)

    850

  • Input impedance (balanced) (Ω)

    100 000

  • Input impedance (single-ended) (Ω)

    100 000

  • Output impedance (balanced) (Ω)

    N/A

  • Output impedance (single-ended) (Ω)

    N/A

  • Max current (A)

    N/A

  • Output power (8Ω) (W)

    160

  • Output power (4Ω) (W)

    300

  • Gain (dBu)

    N/A

  • Frequency response low +/- 3dB (Hz)

    2

  • Frequency response high +/- 3dB (Hz)

    1 000 000

  • Signal to Noise Ratio (dB)

    N/A

  • Total Harmonic Distortion + Noise (0% global feedback) (%)

    N/A

  • Total Harmonic Distortion + Noise (100% global feedback) (%)

    N/A

  • Max power consumption (W)

    950

  • Damping factor

    N/A

  • Dimensions (mm)

    430 x 355 x 178

  • Weight (kg)

    20

  • Official link

    https://www.circlelabs.eu/en/product/power-amplifier-M200
