Power amplifiers stereo — Emotiva BasX A11

Name: BasX A11
Brand: Emotiva
Rating: 100 (1 reviews)

Description, images, technical data and specifications

Emotiva BasX A11
Image source — © Emotiva

The BasX A1 is a single—channel amplifier ideal for delivering dedicated power to the most important speakers in your system. Use A1 to build a high-performance stereo system or to provide the cleanest channel possible for each speaker.

Specifications

Model name
BasX A11
Input sensitivity (mV)
1200
Input impedance (balanced) (Ω)
N/A
Input impedance (single-ended) (Ω)
27 000
Output impedance (balanced) (Ω)
N/A
Output impedance (single-ended) (Ω)
N/A
Max current (A)
N/A
Output power (8Ω) (W)
105
Output power (4Ω) (W)
140
Gain (dBu)
29
Frequency response low +/- 3dB (Hz)
10
Frequency response high +/- 3dB (Hz)
80 000
Signal to Noise Ratio (dB)
>115
Total Harmonic Distortion + Noise (0% global feedback) (%)
N/A
Total Harmonic Distortion + Noise (100% global feedback) (%)
< 0.02
Max power consumption (W)
N/A
Damping factor
>500
Dimensions (mm)
432 × 197 × 394
Weight (kg)
23,1
Official link
https://emotiva.com/products/basx-a11-eleven-channel-power-amplifier
