Power amplifiers stereo — Line Magnetic AS-128PP

Description, images, technical data and specifications

Line Magnetic AS-128PP
Image source — © Line Magnetic

Line Magnetic Audio AS‑128PP is a premium-class tube amplifier. It uses the legendary Western Electric 212 tube, which is valued for its warm, rich sound and hand‑built construction. The model combines vintage aesthetics with advanced audio technologies — a choice for discerning audiophiles.

Specifications

  • Model name

    AS-128PP

  • Input sensitivity (mV)

    500

  • Input impedance (balanced) (Ω)

    N/A

  • Input impedance (single-ended) (Ω)

    100 000

  • Output impedance (balanced) (Ω)

    N/A

  • Output impedance (single-ended) (Ω)

    N/A

  • Max current (A)

    N/A

  • Output power (8Ω) (W)

    2 x 120

  • Output power (4Ω) (W)

    N/A

  • Gain (dBu)

    51 / 63

  • Frequency response low +/- 3dB (Hz)

    10

  • Frequency response high +/- 3dB (Hz)

    70 000

  • Signal to Noise Ratio (dB)

    88

  • Total Harmonic Distortion + Noise (0% global feedback) (%)

    N/A

  • Total Harmonic Distortion + Noise (100% global feedback) (%)

    1

  • Max power consumption (W)

    N/A

  • Damping factor

    N/A

  • Dimensions (mm)

    480 x 280 x 530

  • Weight (kg)

    80

  • Official link

    https://line-magnetic.eu/collections/all
