Power amplifiers stereo — Pro-Ject Amp Box DS2
Description, images, technical data and specifications
Pro-Ject Amp Box DS2
Image source — © Pro-Ject
What is it?
Ask AI to scan specialized sites and forums, evaluate the impressions of using the product, its advantages and disadvantages and get a summary.
Specifications
Model name
Amp Box DS2
Input sensitivity (mV)
550
Input impedance (balanced) (Ω)
N/A
Input impedance (single-ended) (Ω)
10 000
Output impedance (balanced) (Ω)
N/A
Output impedance (single-ended) (Ω)
N/A
Max current (A)
N/A
Output power (8Ω) (W)
100
Output power (4Ω) (W)
140
Gain (dBu)
N/A
Frequency response low +/- 3dB (Hz)
10
Frequency response high +/- 3dB (Hz)
50 000
Signal to Noise Ratio (dB)
N/A
Total Harmonic Distortion + Noise (0% global feedback) (%)
N/A
Total Harmonic Distortion + Noise (100% global feedback) (%)
<0,1
Max power consumption (W)
N/A
Damping factor
N/A
Dimensions (mm)
206 x 68 x 194
Weight (kg)
1.67
Official link
