Power amplifiers stereo — T+A A 3000 HV
Description, images, technical data and specifications
T+A A 3000 HV
Image source — © T+A
The T+A A 3000 HV Silver power amplifier for high-voltage operation, in addition to supporting stereo playback, can easily switch to monaural playback mode. The case is large, and there are two displays on the front that show voltage spikes. High-quality materials were used to manufacture the device.
Specifications
Model name
A 3000 HV
Input sensitivity (mV)
N/A
Input impedance (balanced) (Ω)
N/A
Input impedance (single-ended) (Ω)
N/A
Output impedance (balanced) (Ω)
N/A
Output impedance (single-ended) (Ω)
N/A
Max current (A)
N/A
Output power (8Ω) (W)
380 (Stereo) + 430 (Mono)
Output power (4Ω) (W)
700 (Stereo) + 800 (Mono)
Gain (dBu)
N/A
Frequency response low +/- 3dB (Hz)
0.5
Frequency response high +/- 3dB (Hz)
180 000
Signal to Noise Ratio (dB)
> 115 dB
Total Harmonic Distortion + Noise (0% global feedback) (%)
N/A
Total Harmonic Distortion + Noise (100% global feedback) (%)
< 0,03
Max power consumption (W)
N/A
Damping factor
> 65
Dimensions (mm)
170 x 460 x 460
Weight (kg)
38
