Power amplifiers stereo — Soulution Audio 312 stereo amplifier
Description, images, technical data and specifications
Soulution Audio 312 stereo amplifier
Image source — © Soulution Audio
Specifications
Model name
312 stereo amplifier
Input sensitivity (mV)
N/A
Input impedance (balanced) (Ω)
2000
Input impedance (single-ended) (Ω)
N/A
Output impedance (balanced) (Ω)
N/A
Output impedance (single-ended) (Ω)
N/A
Max current (A)
30
Output power (8Ω) (W)
100
Output power (4Ω) (W)
200
Gain (dBu)
26
Frequency response low +/- 3dB (Hz)
0
Frequency response high +/- 3dB (Hz)
800 000
Signal to Noise Ratio (dB)
N/A
Total Harmonic Distortion + Noise (0% global feedback) (%)
N/A
Total Harmonic Distortion + Noise (100% global feedback) (%)
< 0.0004
Max power consumption (W)
N/A
Damping factor
>5000
Dimensions (mm)
430 x 490 x 142
Weight (kg)
17
