Power amplifiers mono — Audia Flight STRUMENTO n° 8 Signature
Description, images, technical data and specifications
Audia Flight STRUMENTO n° 8 Signature
Image source — © Audia Flight
An amplifier with fully balanced circuitry has 48 solid-state elements in the output stages, 217 thousand UF of the total capacity of the filter capacitors in the power supply, a transformer rated at 3 kVA and has an impressive output power of 2000 watts at a load of 2 ohms (500 watts at 8 ohms).
Specifications
Model name
STRUMENTO n° 8 Signature
Input sensitivity (mV)
1410
Input impedance (balanced) (Ω)
7500
Input impedance (single-ended) (Ω)
7500
Output impedance (balanced) (Ω)
N/A
Output impedance (single-ended) (Ω)
N/A
Max current (A)
N/A
Output power (8Ω) (W)
650
Output power (4Ω) (W)
1300
Gain (dBu)
29
Frequency response low +/- 3dB (Hz)
0,3
Frequency response high +/- 3dB (Hz)
1 000 000
Signal to Noise Ratio (dB)
110
Total Harmonic Distortion + Noise (0% global feedback) (%)
N/A
Total Harmonic Distortion + Noise (100% global feedback) (%)
< 0,05
Max power consumption (W)
1200
Damping factor
>1000
Dimensions (mm)
450 x 280 x 500
Weight (kg)
103.5
Official link
