Power amplifiers mono — Bryston 7B Cubed
Description, images, technical data and specifications
Bryston 7B Cubed
Image source — © Bryston
The Bryston 7B3 mono amplifier is really special. Although it doesn't differ much from each other, it's a big step forward compared to the venerable 4B3. The power supply for the 7B3 amplifier is built around a transformer with a special winding, which is significantly more efficient than a conventional one. With twice the available power, it can manage all but the toughest loads to near-real levels. But even at the level of a whisper, it reveals details and nuances in your recordings that you didn't even know about until now.
Specifications
Model name
7B Cubed
Input sensitivity (mV)
N/A
Input impedance (balanced) (Ω)
5000
Input impedance (single-ended) (Ω)
7500
Output impedance (balanced) (Ω)
N/A
Output impedance (single-ended) (Ω)
N/A
Max current (A)
N/A
Output power (8Ω) (W)
600
Output power (4Ω) (W)
900
Gain (dBu)
N/A
Frequency response low +/- 3dB (Hz)
1
Frequency response high +/- 3dB (Hz)
100 000
Signal to Noise Ratio (dB)
119 (XLR), 117 (RCA)
Total Harmonic Distortion + Noise (0% global feedback) (%)
N/A
Total Harmonic Distortion + Noise (100% global feedback) (%)
<0.005
Max power consumption (W)
N/A
Damping factor
N/A
Dimensions (mm)
480 х 160 х 411
Weight (kg)
27
Official link
