Integrated amplifiers — Musical Fidelity M3SI

Description, images, technical data and specifications

Musical Fidelity M3SI
Image source — © Musical Fidelity

The device is made according to the classical "double mono" scheme, which ensures the identity of the characteristics of the left and right channels. The level of its nonlinear distortion, measured at a frequency of 1 kHz, does not exceed 0.007%, and at a frequency of 10 kHz it is only 0.01%.

Specifications

  • Model name

    M3SI

  • Type

    Integrated Amplifier with DAC and Phono

  • Analog inputs (balanced)

    1

  • Analog inputs (single-ended)

    4 + 1 (Phono)

  • Input sensitivity (mV)

    N/A

  • Input impedance (balanced) (Ω)

    N/A

  • Input impedance (single-ended) (Ω)

    N/A

  • Output impedance (balanced) (Ω)

    N/A

  • Output impedance (single-ended) (Ω)

    N/A

  • D/A conversion

    Yes

  • Phono MM/MC current-sensing input impedance (Ω)

    50 000 (MM)

  • Output power (8Ω) (W)

    85

  • Output power (4Ω) (W)

    N/A

  • Gain (dBu)

    N/A

  • Frequency response low +/- 3dB (Hz)

    10

  • Frequency response high +/- 3dB (Hz)

    20 000

  • Signal to Noise Ratio (dB)

    98

  • Total Harmonic Distortion + Noise (%)

    <0.014

  • Damping factor

    N/A

  • Dimensions (mm)

    440 x 100 x 400

  • Weight (kg)

    9.2

  • Official link

    https://www.musicalfidelity.com/products/m3series/m3si
