Integrated amplifiers — Cambrige Audio CXA61

Name: CXA61
Brand: Cambrige Audio
Rating: 100 (1 reviews)

Description, images, technical data and specifications

Cambrige Audio CXA61
Image source — © Cambrige Audio

The Cambridge Audio CXA 61 integrated amplifier is made in a metal case with an aluminum front panel of considerable thickness. In its center there is a control and display unit, and the handle on the right is designed to perform several functions. In addition to the large volume control knob based on the Alps variable resistor, there are also miniature controls for stereo balance and timbre in the low and high frequencies. On the opposite side of the front panel there is a headphone jack and an additional input for portable sources on the mini-jack connector. The amplifier is equipped with a remote control.

Specifications

Model name
CXA61
Type
Integrated Amplifier with DAC
Analog inputs (balanced)
N/A
Analog inputs (single-ended)
4
Input sensitivity (mV)
N/A
Input impedance (balanced) (Ω)
N/A
Input impedance (single-ended) (Ω)
N/A
Output impedance (balanced) (Ω)
N/A
Output impedance (single-ended) (Ω)
N/A
D/A conversion
Yes
Phono MM/MC current-sensing input impedance (Ω)
N/A
Output power (8Ω) (W)
60
Output power (4Ω) (W)
90
Gain (dBu)
N/A
Frequency response low +/- 3dB (Hz)
5
Frequency response high +/- 3dB (Hz)
60 000
Signal to Noise Ratio (dB)
95
Total Harmonic Distortion + Noise (%)
0.002
Damping factor
90
Dimensions (mm)
115 x 341 x 430
Weight (kg)
8.3
Official link
https://www.cambridgeaudio.com/row/en/products/hi-fi/cx-series-2/cxa61
